Valtra T series Versu

2.4 Control panel for A-pillar display and Proline
5
20
30
40
50
0
5
0
20
25
30
1
2
3
4
5
6
GUID-983CD1D6-7614-41B0-8D19-1E07FB1000A9
1. Proline instrument panel selection
2. Arrow up
3. A-pillar display selection
4. Back
5. Arrow down
6. SET / selection
NOTE: Moving back in the selection menu automatically saves the selection.
When power is switched on, the control panel controls the Proline instrument
panel as a default.
2.5 Proline instrument panel
The operator receives information from the gauges, coolant thermometer,
tachometer, speedometer and indicator lights. All this can be seen on the Proline
instrument panel.
5
20
30
40
50
0
5
0
20
25
30
1
2
3
4
5
3
6
7
GUID-288866C1-6188-4BEE-8DE6-85ABC831721E
2. Instruments and controls
- 30 -
