To switch on the right-hand side turn signal, move the multifunction lever
downwards.
The left or right indicator light blinks correspondingly.
3.5.2 Using the horn
5
20
30
40
50
0
5
0
20
25
30
1
GUID-39F97DFA-F605-48D5-853D-004FFCF16415
1. Horn button
To sound the horn, push the horn button.
3.5.3 Using the rotary beacon light
Rotary beacon light is an extra equipment.
OK
1 2
1
GUID-6F8BE120-48CF-48FF-AAC3-AF25A59C59B9
1. Button for rotary beacon light
1. Press the button for rotary beacon light to switch the beacon on or off.
When on, the symbol on the button is lit green.
NOTE: The rotary beacon light (optional) can be turned on from the light
panel also when the panel or the driving or parking lights are switched off.
3. Operation
- 81 -
