Symbol Function
Rear linkage raised to the transport position
Engine speed cruise control
Driving speed cruise control
Battery level voltage
Urea level in percent
Cruise control views, displaying the following information:
Constant engine speed 1 (rpm)
Constant driving speed 1 (km/h/mph)
Constant driving speed 2 (km/h/mph)
3.12.11.1 Power take-off speed views
Front PTO speed
C3
A5
B4
RPM
480
Km
2.18
0
AUTO 1
P
GUID-29128F5B-50A8-4783-B5B5-1108B2711C4D
Rear PTO speed
C3
A5
RPM
480
Km
2.18
B4
0
AUTO 1
P
GUID-48551897-CE3E-45D2-BF8A-45CDF71656EA
The PTO rotation speed is shown with an accuracy of 10 rpm.
3. Operation
- 167 -
