Example
Activate current socket with U-Pilot programme
Current socket activated.
End of the programme.
3.19.6 Using U-Pilot programmes
3.19.6.1 Selecting a U-Pilot programme
1. Press ESC button.
2. Navigate to the menu 2 with the up and down arrow buttons.
3. Press the left arrow button to enter the U-Pilot view.
GUID-18F4B804-649E-4F09-8665-DFF68C1A4F70
4. Select the memory slot with the left and right arrow buttons.
5. Press the OK button or the selector for the predefined factory/user settings.
6. Move the selection to the programme selection menu with the left and right
arrow buttons.
7. Press the OK button or the selector for the predefined factory/user settings.
3,5
m
ABC
1 2
IMPL1IMPL1
NEW_1
BACKUP
IMPL2
PLOUGH1
PLOUGH2
IMPL3
GUID-465DB634-6FC6-4E00-8CBB-C5ADFF07AFD3
8. Press the up and down arrow buttons or rotate the selector for the predefined
factory/user settings to select the U-Pilot programme.
NOTE: You can discard the made changes and return the previous view by
pressing ESC.
9. Press the OK button or the selector for the predefined factory/user settings.
The programme is selected and the hydraulics settings are copied to the
auxiliary hydraulics' U-Pilot memory position.
With a short press of the ESC button you can return to the menu 2. A long press
of the ESC button returns to the previously active drive display.
3. Operation
- 254 -
