6.7.4 Air cleaner
Air cleaner Two-stage, dry element, with blockage indicator
Pre-cleaner system Ejector
6.7.5 Cooling system
Pump Centrifugal
Radiator Pressurised with expansion tank regulated by
pressure cap
Thermostat 2 thermostats: 79°C and 83°C
Fan The belt-driven fan is controlled by the engine's
control module for precise fan speed modulation
Coolant Water and antifreeze agent (standard ASTM D 3306
or BS 6580:1992)
Coolant volume 28 litres
6.8 Electrical system
Ground Negative
Voltage 12 V
Battery 174 Ah
Alternator 150 A
Starter motor 4.3 kW
Suction air preheater (engine induction air) 2.1 kW
Fuses
Cab electric centre 36 fuses
The nominal current rating of the fuses is 5–25 A.
Roof electric centre 25 fuses
The nominal current rating of the fuses is 10–30 A.
Main fuse centre 4 fuses
The nominal current rating of the fuses is 25–250 A.
Engine electric centre 12 fuses
The nominal current rating of the fuses is 3–25A.
Electric preheating of engine induction air 250 A
Cab power supply 125 A
Bulbs
Headlights 55 W-H7
Front position (side) lamps 10 W
Rear/brake lights LED
Direction indicators 21 W front / LED rear
Working lights 65 W-H9
Cab lights LED options
Current sockets
Two-pin current socket ISO 4165
Three-pin current socket ISO/TR 12369
Trailer socket ISO 1724
6. Technical specifications
- 426 -
