4.7.5.9 Adjusting the front wheel toe-in
Adjust the front wheel toe-in if needed.
Before you adjust the toe-in, check that there is no free play in the ball joints of
the steering arms and tie rod.
NOTE: In order not to limit the steering movement, both tie rods must be
adjusted.
1. Centre the wheels.
2. Loosen the tie rod locking nut.
GUID-3597A987-BED1-435C-84DA-90EA697AC8DD
1. Locking nut
2. Adjustment screw
3. Turn the adjustment screw in the right direction.
4. Measure both tie rods.
IMPORTANT: Both tie rods must be of the same length after the adjustment.
5. Tighten the locking nut when the correct distance has been achieved.
6. Check the toe-in.
4.7.5.10 Changing the hydraulic breather
Change the hydraulic breather periodically.
IMPORTANT: If the tractor is used continuously in dusty conditions, the breather
must be changed more frequently.
4. Maintenance
- 364 -
