3.14.6.1 Setting automatic side limiters to fixed position
GUID-4CDE4C5B-B4A3-413A-99C2-AF79D4A77346
1. Holding chain
2. Limiting pin
1. Adjust the chain to the length where it does not release the side limiter's
locking when the linkage is lowered down.
2. Pull out the limiting pin.
3. Adjust the length of the side limiter.
4. Put the limiting pin back to lock the length of the side limiter.
3. Operation
- 205 -
