3.13.13.1 Using the drive balance control
AUTO
CONTROL
1
2
OFF
ON
OFF
AUTO
CONTROL
GUID-2BD3C84A-519F-41EB-90B3-8163EE517270
1. Drive balance control knob
2. Drive balance position
3. Drive balance control light
4. Lift/stop/lower switch
1. To activate the drive balance control, turn the drive balance control selector
to the drive balance position.
The drive balance control light is lit when the balance control is activated.
2. Set the lift/stop/lower switch to the lift (transport) position.
3. To deactivate the drive balance control, turn the drive balance control
selector to the off position.
3.13.14 Slip control
The slip control is extra equipment.
You can use the slip control when working with implements that operate below
the surface of the ground and are connected to the three-point linkage.
NOTE: The slip control operates only when the draft control is activated.
The slip control function lifts the linkage when the wheels exceed the slip limit. It
lowers the implement back to the set depth when the wheel slip is below the slip
limit again.
3. Operation
- 194 -
