• Make sure that the locking latch moves to both extreme positions.
When the locking latch is turned upwards the Nordic and Euro pick-up hitch
must move up 6-8 mm and the hydraulic pick-up hitch must move up 8–10
mm.
• Check the wear of the pick-up hitch.
The distance between the pick-up hitch and mating surface must be under
10 mm.
WARNING: When the pick-up hitch has worn down to 44 mm at
the thinnest part, it has to be replaced.
4.7.3.3 Greasing the Nordic and Euro pick-up hitch
Grease the pick-up hitch periodically.
NOTE: Use Universal Grease for greasing.
• Apply grease to the grease nipples.
GUID-7704173A-3B50-4FEE-8E6A-A36002691B76
1. Grease nipple
4. Maintenance
- 322 -
