3.23.6 Agricultural drawbar
The agricultural drawbar (optional) is used without the pick-up hitch.
GUID-7C0D87A3-6EED-45AA-8870-A33EC5DDD993
1. Agricultural drawbar
The agricultural drawbar is used for towing implements where only part of the
implement weight is on the drawbar, for example balers. See the technical
specifications in this manual for the maximum weight of the drawbar implement.
Agricultural drawbar:
• Adjustable to three different distances from the power take-off (PTO) shaft.
• In all positions, the drawbar can also be adjusted ±12.5° and ±25° to either
side.
3. Operation
- 283 -
