PaX-i (PCH-2500) User Manual

6. Acquiring PANO Images

⑥

Orthogonal_Bitewing

A panoramic imaging mode to acquire an image only for the

region of interest through the orthogonal trajectory:

Pros

: less

X-Ray exposure than the Normal mode.

Cons

: TMJ and parts

of an image of the maxillary sinus are not acquired.

⑦

TMJ LAT Open / Close

An imaging mode to acquire a lateral image of the TMJ, in

which the X-Ray beam is directed on the lateral TMJ region:

TMJ (Open and Close).

⑧

TMJ PA Open / Close

An imaging mode to acquire a TMJ image, in which the X-Ray

beam is directed on the frontal TMJ, with the patient's mouth

open fully and close (Open and Close).

X-Ray ON

Pi_u272_en_20180514.indd 63 2018-05-14 오전 11:03:22
