11. Technical Specications
Item Description
Weight (kg)
Without CEPH
unit
90 (198.4 lbs)
With base: 137 (302 lbs)
With CEPH unit
(Scan type)
120 (264.5 lbs)
With base: 167 (368.1 lbs)
With CEPH unit
(One-shot type)
130 (286.6 lbs)
With base: 177 (390.2 lbs)
Total height (mm) Max. 2320 (91.34 in.)
Vertical column movement (mm) Max. 700 (Max. 27.56 in.)
Length x Width x
Height (mm)
Without CEPH
unit
990(L) x 1125(W) x 2320(H)
(38.98(L) x 44.29(W) x 91.34(H) in.)
With CEPH unit
(Scan Type)
1920(L) x 1125(W) x 2320(H)
(75.6(L) x 44.29(W) x 91.34(H) in.)
With CEPH unit
(One-shot Type)
1930(L) x 1125(W) x 2320(H)
(75.98(L) x 44.29(W) x 91.34(H) in.)
Type of installation Base Stand / Wall Mount
* Column Height Limiting Function -> 2300~2000 (Adjustable in 10 mm)
 11.2
Technical Specications
X-Ray Generator
Item Description
Model HDG-07B10T2
Rated output power 0.99 KW
High voltage
generator
Type 40 KHz Inverter Type
Normal/
Pulse
kV 50 ~ 90
mA 4 ~ 10
Cooling
Automatically controlled / Protect
≥ 60
℃
Air Cooling : Optional
Pi_u272_en_20180514.indd 113 2018-05-14 오전 11:03:31

Vatech PAX-I Specifications

General

Focal Spot Size	0.5 mm
Image Receptor	Digital sensor
Compatibility	DICOM 3.0
Image Detector	CMOS
Power Supply	220-240 VAC, 50/60 Hz
Sensor Type	CMOS
X-ray Generator	High Frequency
Tube Voltage	60-90 kVp
Tube Current	4-12 mA
Power Requirements	100-240V AC, 50/60Hz
Usage	Dental diagnostics
