Appendices
Mode Tested: CEPH PA, 12.94 s
mA
4 5 8
[mGy] [mGy
ㆍ
cm2] [mGy] [mGy
ㆍ
cm2] [mGy] [mGy
ㆍ
cm2]
60
0.39 4.66 0.57 6.84 0.73 8.85
70
0.51 6.14 0.75 9.05 0.98 11.80
80
0.65 7.88 0.96 11.57 1.25 15.11
90
0.80 9.68 1.18 14.30 1.55 18.78
 2.2
X-ray Leakage Dose
Test Equipment Information
Instrument Manufacturer Model S / N
Dose Meter Victoreen 660 101114/101377
Test Condition
Test mode Detector kVP mA sec
PANO (HD, Adult)
Xmaru 1501CF 90 10
13.5
PANO (HD, Child) 11.5
CEPH (Scan type) Xmaru 2301CF
90 10
12.9
CEPH (One-shot type) 1210SGA 0.9
Mode
Direction [°]
PANO
(HD, Adult)
PANO
(HD, Child)
CEPH
(Scan type)
CEPH
(One-shot type)
[mR/hr]
0 15.2 15.9 15.1 16.7
45 20.1 17.6 18.5 21.2
90 40.5 33.2 37.3 34.3
100 67.8 66.8 68.9 71.2
110 61.1 19.3 34.5 39.5
kVp
Pi_u272_en_20180514.indd 123 2018-05-14 오전 11:03:32

Vatech PAX-I Specifications

General

Focal Spot Size	0.5 mm
Image Receptor	Digital sensor
Compatibility	DICOM 3.0
Image Detector	CMOS
Power Supply	220-240 VAC, 50/60 Hz
Sensor Type	CMOS
X-ray Generator	High Frequency
Tube Voltage	60-90 kVp
Tube Current	4-12 mA
Power Requirements	100-240V AC, 50/60Hz
Usage	Dental diagnostics
