Vatech PAX-I User Manual

PaX-i (PCH-2500) User Manual
42
4. Software Overview
 4.3
Imaging Software Overview
Imaging parameters can be set using the imaging program.
The following screenshot shows the main interface in PANO mode
.
For details
concerning PANO and CEPH imaging, refer to sections
4.3.1 - 4.3.2.
A. Imaging Mode Display
This displays the current imaging mode.
NOTE
- Indicates that the Magic PAN is supported in the PANO
imaging modality.
- Is displayed only in the ‘Standard’ mode, with the Magic
PAN-enabled.
A
I J
G H
K
N
O
M
L
B
C
D
E
F
Pi_u272_en_20180514.indd 42 2018-05-14 오전 11:03:16

Vatech PAX-I Specifications

General

Focal Spot Size	0.5 mm
Image Receptor	Digital sensor
Compatibility	DICOM 3.0
Image Detector	CMOS
Power Supply	220-240 VAC, 50/60 Hz
Sensor Type	CMOS
X-ray Generator	High Frequency
Tube Voltage	60-90 kVp
Tube Current	4-12 mA
Power Requirements	100-240V AC, 50/60Hz
Usage	Dental diagnostics
