PaX-i (PCH-2500) User Manual

110

11. Technical Specications

11.

Technical Specications

 11.1

Mechanical Specications

A. Image Magnication

Mode FDD (mm) FOD (mm) ODD (mm) Magnication

PANO 490.3 375.5 114.8 1.3 constant

CEPH 1,745 1,524 221

1.14

constant

FDD : Focal Spot to Detector Distance

FOD : Focal Spot to Object Distance

ODD : Object to Detector Distance (ODD = FDD - FOD)

Magnication = FDD / FOD

B. Dimension

- Without Cephalometric Unit & Non-Base type

[Unit: mm (Inches)

Pi_u272_en_20180514.indd 110 2018-05-14 오전 11:03:30
