Vatech PAX-I User Manual

PaX-i (PCH-2500) User Manual
98
7. Acquiring CEPH Images
 7.3
Initiating X-Ray Exposure
The X-Ray exposure method and process is the same for all CEPH modes.
The example and images below are taken from an X-Ray performed in
CEPH
Lateral mode.
WARNING
If a problem occurs during image acquisition, press the
red emergency stop button to immediately stop all moving
parts and cut off the power to the equipment’s electrical
components. You may then proceed to release the patient
safely from the equipment.
To reset the emergency button, turn it clockwise until it
pops up.
WARNING
- Do not operate the PC during exposure. Failure to
comply with this instruction may cause the system to
malfunction.
- The operator shall observe the X-Ray safety regulations
applicable to their area at all times during the operation
of this equipment.
CAUTION
If an emergency occurs during image acquisition, release
the exposure switch to cease X-Ray emission.
E
M
E
R
G
E
N
C
Y
S
T
O
P
Pi_u272_en_20180514.indd 98 2018-05-14 오전 11:03:29

Vatech PAX-I Specifications

General

Focal Spot Size	0.5 mm
Image Receptor	Digital sensor
Compatibility	DICOM 3.0
Image Detector	CMOS
Power Supply	220-240 VAC, 50/60 Hz
Sensor Type	CMOS
X-ray Generator	High Frequency
Tube Voltage	60-90 kVp
Tube Current	4-12 mA
Power Requirements	100-240V AC, 50/60Hz
Usage	Dental diagnostics
