PaX-i (PCH-2500) User Manual

7. Acquiring CEPH Images

7.2.1 Lateral Mode

Follow the procedure below to position the patient.

A. Widen the distance between the two

ear rods.

NOTE

Porion position reference indicator enables the operator to

easily identify the position of the porion on the image.

B. Guide the patient to the CEPH unit.

C. Ask the patient to stand upright.

Make sure that the patient’s shoulders are

level and that their neck is relaxed.

D. Adjust the height of the unit to suit the

patient by pressing the column up/down

button or switch (optional).

Ear rods

Nasal positioner

*To link to the video

manual: scan the QR

code with smartphone

or pad.
