6. Acquiring PANO Images
6
Acquiring PANO Images
This chapter requires the preparatory steps in
Chapter 5
to have already been
completed. If you have not completed these steps, please return to
Chapter 5
and complete the process outlined there before proceeding with this chapter.
 6.1
PANO Imaging Program
EXAMINATION ARCH SELECTION
EXAMINATION
PROGRAM
PANO
EXAMINATION
Narrow
Standard
Right
Front
Left
Normal
Standard
Right
Front
Left
Wide
Standard
Right
Front
Left
Child
Standard
Right
Front
Left
Orthogonal
Standard
Right
Front
Left
Bitewing
Bitewing Incisor
Bitewing Right
Bitewing Left
SPECIAL
EXAMINATION
-
TMJ LAT Open
TMJ LAT Close
TMJ PA Open
TMJ PA Close
Sinus LAT
Sinus PA
①
②
③
④
⑥
⑤
⑦
⑧
⑨
⑩
Pi_u272_en_20180514.indd 60 2018-05-14 오전 11:03:19

Vatech PAX-I Specifications

General

Focal Spot Size	0.5 mm
Image Receptor	Digital sensor
Compatibility	DICOM 3.0
Image Detector	CMOS
Power Supply	220-240 VAC, 50/60 Hz
Sensor Type	CMOS
X-ray Generator	High Frequency
Tube Voltage	60-90 kVp
Tube Current	4-12 mA
Power Requirements	100-240V AC, 50/60Hz
Usage	Dental diagnostics
