PaX-i (PCH-2500) User Manual
43
4. Software Overview
NOTE
- Indicates that the AF mode is supported in the PANO
imaging modality.
- Is displayed only in the ‘Standard’ mode, with the AF
enabled.
- The AF is incorporated only in the UHD and Intelligent
version.
B. Scanning Status and Image Preview Window
This shows image acquisition progression in real- time.
C. Patient Information
This displays information about the selected patient.
D. Imaging Guide Window
This displays various text instructions for the operator to follow.
E. Scan Time and DAP Display Window
Upon clicking
Conrm,
the scan time and estimated DAP value are displayed
in this window.
F. Tube Voltage and Current Adjustment
This tool adjusts the kVp and mA values or controls the power of the X-Ray
in order to improve image quality. If necessary, adjust the kVp and mA values
manually using the arrows.
NOTE
Adjustable resolution:
- Tube voltage: ± 1 kVp
- Tube current: ± 1 mA
NOTE
For the tube voltage and its correspondence with the
current patient, refer to Appendix 1: Recommended X-Ray
Exposure Table.
Pi_u272_en_20180514.indd 43 2018-05-14 오전 11:03:16

Vatech PAX-I Specifications

General

Focal Spot Size	0.5 mm
Image Receptor	Digital sensor
Compatibility	DICOM 3.0
Image Detector	CMOS
Power Supply	220-240 VAC, 50/60 Hz
Sensor Type	CMOS
X-ray Generator	High Frequency
Tube Voltage	60-90 kVp
Tube Current	4-12 mA
Power Requirements	100-240V AC, 50/60Hz
Usage	Dental diagnostics
