VDO CANcockpit Series User Manual

CANcockpit article description
CCS 52 PressOil 0-5bar S on tb ABCDE
1
23 567
4
8
9
1 Device type
CANcockpit BlackBox - CCB
CANcockpit Master - CCM
CANcockpit Slave - CCS
CANcockpit Harness - CCH
2 Diameter
52 mm - 52
80 mm - 80
85 mm - 85
100 mm - 100
5 Main scale
min. "-" max. unit
6 Dial scale
Single scale - S
Double scale - D
3 Gauge
Ammeter - Am Speedometer - Speedo
Level - Level Tachometer - Tacho
Pressure - Press Temperature - Temp
Pyrometer - Pyro Voltmeter - Volt
Rear Wheel - RearW
7 ISO symbol
Off-road - "none"
On-road - on
Without - wo
8 Bezel
Triangle black - tb
Triangle chrome - tc
4 Reference
AdBlue - AdBlue Hydraulics - Hy
Air - Air Transmission - Tr
Brake - Br Turbo - Tu
Engine Oil - Oil Water - Wa
Freshwater - Fw Wastewater - Ww
Fuel - Fuel
9 Customer
optional
