Vertiv NetSure 5100 Series Installation Manual

Vertiv™ NetSure™ 5100 Series -48 VDC Power System Installation Manual
Proprietary and Confidential © 2023 Vertiv Group Corp.
163
Checking Basic System Settings
Navigate through the controller menus and submenus to check system settings. You can adjust any parameter as required. Note
that these settings can also be checked (and changed if required) via the WEB Interface. Refer also to “NCU Start Wizard” on page
162.
NOTE! Repeatedly press the “ESC” key to return in reverse order level by level from any submenu until the Main Menu
appears.
Procedure
1. To Select a Sub-Menu:
Press the UP and DOWN keys to highlight the desired sub-menu. Press the ENT key to enter the selected sub-menu.
2. To Select a User:
To select a User, use the UP and DOWN keys to move the cursor to the Select User field. Press ENT. Use the UP and DOWN
keys to select a User previously programmed into the NCU. Press ENT to select the User. Note that only Users programmed
into the NCU are shown. Users are programmed via the Web Interface. The default User is admin.
3. To Enter a Password:
If a password screen opens, a password must be entered to allow the User to make adjustments. To enter a password, use
the UP and DOWN keys to move the cursor to the Enter Password field. Press ENT. Use the UP and DOWN keys to choose a
character. Press ENT to accept and move to the next character. Continue this process until all characters are entered.
Press ENT again to accept the password. The default password is 640275.
4. To Change a Parameter:
Press the UP and DOWN keys to move up and down the list of parameters. Press ENT to select the parameter. Press the UP
and DOWN keys to change the parameter. Press ENT to make the change. Press ESC to cancel the change.
5. Table 7.1 shows the menu navigation for some basic settings. Refer to the separate NCU Manual (UM1M830BNA) supplied
with your power system for complete Local Display menus.
Changing Battery Capacity Rating in the NCU
1. Change the battery capacity setting of the NCU to match the battery connected to the power system.
NOTE! After setting the battery capacity, the User should also reset the battery capacity (battery must be fully charged).
Local Menu Navigation:
Main Menu / Settings Icon / Batt Settings / Batt1 Settings / Rated Capacity.
Web Menu Navigation:
Settings Menu / Battery Tab / Batt1 Rated Capacity.
2. Reset the battery capacity (resets the battery capacity calculation).
NOTE! Only reset the battery capacity when the battery is fully charged; otherwise, the battery charge status may not be
accurate.
Local Menu Navigation:
Main Menu / Settings Icon / Batt Settings / Basic Settings / Reset Batt Cap.
Web Menu Navigation:
Settings Menu / Battery Tab / Reset Battery Capacity.
Refer to the NCU Instructions (UM1M830BNA) for detailed instructions.
