VideoIQ User Guide49
3. Select an option from the Stream Over drop-down menu:
UDP: This is the most bandwidth-efficient selection. However, this
protocol is not allowed to pass through all firewalls. If you’re having
trouble seeing live streaming video, select either TCP or HTTP(S).
TCP: Encapsulates the RTP traffic into standard TCP packets and
streams it to the client. Select this protocol if your firewall will not pass
UDP traffic.
HTTP(S): The least bandwidth-efficient selection. This encapsulates RTP
and RTSP into HTTP transfers. The advantage of this streaming method
is that it uses one port for
Web browsing to the camera
Video streaming
Audio streaming
When you use this streaming protocol, separate ports for RTSP and
Audio are no longer required.
When using port mapping on a router with an externally accessible IP
address, click the Use Custom Ports checkbox and enter the port
numbers in the Control Port, HTTP(S) Port, RTSP Port, and Audio Output
Port fields.
Port Function Default Value Type
Control Port Secure communication
between View and the iCVR
takes place through this port
5401 TCP
HTTPS Port Encrypted file transfer and
web access to the camera
take place through this port.
Choose to run the camera over
HTTPS or HTTP
443 TCP
