8-10 Videojet DataFlex 6530 Operator Manual - Rev AA
Troubleshooting
Intermittent Mode Only:
Substrate is moving while
printer is printing
Navigate to Tools > Setup> Printhead.
If substrate is not settled before printer
begins to print, adjust Print Delay.
If substrate begins to advance before
printer finishes printing, increase Print
Speed.
Intermittent Mode Only:
Incorrect Print Speed setting
Navigate to Tools > Setup >Printhead and set
Print Speed to default of 200mm/sec.
Check for print and adjust accordingly.
Worn or damaged printhead Replace the printhead.
Invalid or corrupt Job
selected
Select a different or valid Job.
Incorrect Printhead Mapping Connect with CLARiTY Configuration
Manager and ensure correct Printhead
Mapping.
Printer will not
go ONLINE
Invalid or no Job selected Select a valid Job.
Fault message not cleared Clear the fault message.
Error Message Possible Causes
Remedies
Table 8-1: Printer Faults (continued)
