Chapter 11 Integrated OBs SFBs SFCs Manual VIPA CPU 21x
11-22 HB103E - Rev. 05/45
Via the parameter Ret_Val you get an error number in return. See the table
below for the concerning error messages:
Value Description
0000h No error
8002h The chosen channel is not configured as counter
(Error in the hardware configuration)
8008h Parameter “Direction” outside the permissible range
8009h Parameter “Channel” outside the permissible range
9001h Internal error:
There was no valid address for a parameter
9002h Internal hardware error:
Please call the VIPA-Service.
Per SetCounter=true the value given by PresetValue is transferred into the
according counter.
The Bit is set back from the SFC.
Value range: true, false
Ret_Val
SetCounter
