Chapter 5 Deployment CPU 21x-2BT02 with H1 / TCP/IP Manual VIPA CPU 21x
5-24 HB103E - Rev. 05/45
Configuration example CPU 21x-2BT02
This chapter provides an introduction to use the bus system TCP/IP for the
System 200V. The object of this chapter is to create a small
communication system between two VIPA CPU 21x-2BT02 that provides a
simple approach to the control of the communication processes.
Knowledge of the CP handler blocks is required. CP handler blocks are
standard function blocks. These provide the options required to use the
communication functions in the applications of the programmable logic
controllers.
The minimum technical equipment required for the examples is as follows:
Hardware
- 2 CPU 21x-2BT02 from VIPA
- 1 PC or PG with twisted-pair Ethernet connection
Communication line
- 3 bus cables
- 1 Mini-Switch CM 240
Software package
- Configuration software WinNCS from VIPA
- Programming package WinPLC7 from VIPA or Siemens SIMATIC
Manager for CPU 21xNET
The implementation of the example is to program the two CPUs as well as
configuring the communication processors by means of WinNCS.
Note!
The complete example is stored at our ftp-server at:
ftp.vipa.de/support/software/demo_files.
You may transfer the PLC application directly to both CPUs.
Overview
Outline and
requirements
