Manual VIPA CPU 21x Chapter 3 Deployment CPU 21x
HB103E - Rev. 05/45 3-1
Chapter 3 Deployment CPU 21x
This chapter describes the deployment of the CPU 21x together with the
peripheral modules of the System 200V.
Besides commissioning and start-up behavior you will find here also a
description of the project engineering, parameterization, operating modes
and test functions.
This information also basically applies to the deployment of the CPU 21x
with integrated communication part.
The following section contains a description of:
• Assembly and commissioning
• Principle of address allocation
• Project engineering and parameterization
• Deployment of MPI and MMC
• Operating modes and overall reset and firmware update
• Usage of test functions
Topic Page
Chapter 3
Deployment CPU 21x......................................................3-1
Assembly..............................................................................................3-2
Start-up behavior.................................................................................. 3-3
Address allocation................................................................................3-4
Project engineering ..............................................................................3-6
Configuration of the CPU parameters ..................................................3-9
Project transfer................................................................................... 3-11
Operating modes................................................................................3-14
Overall Reset .....................................................................................3-15
Firmware update ................................................................................3-17
Using test functions for the control and monitoring of variables.......... 3-20
Note!
This information is valid for all the CPUs described in this manual since the
backplane bus communication between the CPU and the peripheral
modules is the same for all models of this CPU!
