VIPA CPU 21 Series User Manual

Manual VIPA CPU 21x Chapter 12 Instruction list
Command
Operand Parameter Status word Function
Length
in
BR CC1 CC0 OV OS OR STA RLO /FC
words
: Instruction depends on
: Instruction influences
HB103E - Rev. 05/45 12-19
Setting/resetting bit addresses
Set/Reset bit addresses
Status word
A
ssign the value "1" or "0" or the RLO to the
addressed instructions.
S
BR CC1 CC0 OV OS OR STA RLO /FC
Set ...
I/Q a.b
0.0 to 127.7
- - - - - - - Y - input/output to "1". 1/2
M a.b
0.0 to 1023.7
- - - - - 0 Y - 0 set bit memory to "1". 1/2
L a.b
0.0 to 1043.7
local data bit to "1". 2
DBX a.b
0.0 to 8191.7
data bit to "1". 2
DIX a.b
0.0 to 8191.7
instance data bit to "1". 2
c [AR1,m] register-indirect, area-internal (AR1) 2
c [AR2,m] register-indirect, area-internal (AR2) 2
[AR1,m] area-crossing (AR1) 2
[AR2,m] area-crossing (AR2) 2
Parameter via parameters 2
R
BR CC1 CC0 OV OS OR STA RLO /FC
Reset ...
I/Q a.b
0.0 to 127.7
- - - - - - - Y - input/output to "0". 1/2
M a.b
0.0 to 1023.7
- - - - - 0 Y - 0 set bit memory to "0". 1/2
L a.b
0.0 to 1043.7
local data bit to "0". 2
DBX a.b
0.0 to 8191.7
data bit to "0". 2
DIX a.b
0.0 to 8191.7
instance data bit to "0". 2
c [AR1,m] register-indirect, area-internal (AR1) 2
c [AR2,m] register-indirect, area-internal (AR2) 2
W [AR1,m] area-crossing (AR1) 2
W [AR2,m] area-crossing (AR2) 2
Parameter via parameters 2
=
BR CC1 CC0 OV OS OR STA RLO /FC
Assign ...
I/Q a.b
0.0 to 127.7
- - - - - - - Y - RLO to input/output 1/2
M a.b
0.0 to 1023.7
- - - - - 0 Y - 0 RLO to bit memory 1/2
L a.b
0.0 to 1043.7
RLO to local data bit 2
DBX a.b
0.0 to 8191.7
RLO to data bit 2
DIX a.b
0.0 to 8191.7
RLO to instance data bit 2
c [AR1,m] register-indirect, area-internal (AR1) 2
c [AR2,m] register-indirect, area-internal (AR2) 2
[AR1,m] area-crossing (AR1) 2
[AR2,m] area-crossing (AR2) 2
Parameter via parameters 2
