VIPA CPU 21 Series - Application Fields

Manual VIPA CPU 21x Chapter 1 Principles
HB103E - Rev. 05/45 1-13
Application fields
This series of CPU modules provides access to the peripheral modules of
the VIPA System 200V. You can use a set of standard commands and
programs to interrogate sensors and actuators. One single CPU may
address a maximum of central 32 modules.
Compact centralized configuration
CPU
AI 4 AO 4 DIO 8 DO 16
CPU 21x
DO 8 Co un t
Decentralized configuration using Profibus
3
Input/output periphery
CPU 21x DP
5
Input/output periphery
CPU 21x DP
CPU IM 208
5
CPU IM 208
1,3
IM 253
1
Input/output periphery
IM 253
2
Input/output periphery
CPU IM 208
2,4
IM 253
4
Input/output periphery
Input/output periphery
Overview
Application
example
