Manual VIPA CPU 21x Chapter 2 Hardware description
HB103E - Rev. 05/45 2-23
Technical data
Electrical data VIPA 214-1BC02, VIPA 214-1BA02 ... VIPA 216-1BA02
Power supply DC 24V (20.4 ... 28.8V)
Current consumption max. 1.5A
Dissipation power max. 3.5W
Status indicators (LEDs) by means of LEDs located on the front
Connections / interfaces MP
2
I interface for data communication
Clock, memory/clock backup yes / Lithium accumulator, 30 days backup
Output current to backplane bus max. 3A
Bit memory 8192 Bit (M0.0…M255.7)
Timer 256 (T0...T255)
Counters 256 (Z0 ... Z255)
Number of Blocks FB
FC
DB
1024 (FB0...FB1023)
1024 (FC0...FC1023)
2047 (DB1...DB2047)
Total addressing space input / output 1024/1024Byte, each 128 Byte for process image (PA)
Process image Inputs 1024Bit (I0.0...I127.7)
Process image Outputs 1024Bit (O0.0...O127.7)
Combination with peripheral modules
max. no. of modules 32
max. digital I/O 32
max. analog I/O 16
Addressable inputs, outputs 1024 (digital), 128/128 (analog)
Dimensions and weight
Dimensions (WxHxD) in mm 25.4x76x80
Weight 80g
CPU 214C CPU 214 CPU 215 CPU 216
Work memory 32kByte 48kByte 96kByte 128kByte
Load memory 40kByte 80kByte 144kByte 192kByte
Cycle time bit operations
0.18µs 0.18µs 0.18µs 0.18µs
Cycle time word operations
0.78µs 0.78µs 0.78µs 0.78µs
Order-No.: 214-1BC02 214-1BA02 215-1BA02 216-1BA02
CPU 21x
General
Module specific
