VIPA CPU 21 Series User Manual

Chapter 2 Hardware description Manual VIPA CPU 21x
2-24 HB103E - Rev. 05/45
Electrical data VIPA 214-2BT10 ... VIPA 216-2BT10
Power supply DC 24V (20.4 ... 28.8V)
Current consumption max. 1.5A
Dissipation power max. 6W
Potential separation
≥ 500V AC to Ethernet
Status indicator (LEDs) like CPU 21x additionally with LEDs for the Ethernet section
Connections/interfaces like CPU 21x additionally with RJ45 jack (Ethernet)
Ethernet interface CP 243
Connector RJ45
Network topology Star topology
Medium Twisted pair
Transfer rate 10/100Mbit
Overall length max. 100m per segment
PG/OP channel 8 (32 with CP firmware version 1.7.4 and up)
Configurable connections: 16
Dimensions and weight
Dimensions (WxHxD) in mm 50.8x76x80
Weight 150g
Electrical data VIPA 214-2BT02 ... VIPA 216-2BT02
Power supply DC 24V (20.4 ... 28.8V)
Current consumption max. 1.5A
Dissipation power max. 6W
Potential separation
≥ 500V AC to Ethernet
Status indicator (LEDs) like CPU 21x additionally with LEDs for the Ethernet section
Connections/interfaces like CPU 21x additionally with RJ45 jack (Ethernet)
Ethernet interface CP 243
Connector RJ45
Network topology Star topology
Medium Twisted pair
Transfer rate 10Mbit
Overall length max. 100m per segment
PG/OP channel -
Configurable connections: 32
Dimensions and weight
Dimensions (WxHxD) in mm 50.8x76x80
Weight 150g
CPU 21x-2BT10
CPU 21x-2BT02
