Manual VIPA CPU 21x Chapter 2 Hardware description
HB103E - Rev. 05/45 2-25
Electrical Data VIPA 214-2BM02 ... VIPA 216-2BM02
Power supply DC 24V (20.4 ... 28.8V)
Current consumption max. 1.5A
Dissipation power max. 5W
Potential separation
≥ 500V AC to fieldbus
Status monitoring (LEDs) like CPU 21x additionally with LEDs for the Profibus section
Adapters/interfaces like CPU 21x additionally with 9pin D-type jack (Profibus)
Profibus interface
Connector 9pin D-type jack
Network topology Linear bus, active bus termination at both ends
Medium Screened and drilled twisted pair cable. Depending on
environment screening may be omitted.
Transfer rate 9.6kBaud up to 12MBaud
Overall length 100m at 12 MBaud without repeater, up to 1000m with repeater
max. no. of stations 32 stations on every segment without repeater. Expandable to
126 stations with repeater.
Combination with
peripheral modules
max. number of slaves 125
max. number of input bytes 1024
max. number of output bytes 1024
Dimensions and Weight
Dimensions (WxHxD) in mm 50.8x76x80
Weight 150g
Electrical data VIPA 214-2BP02 ... VIPA 216-2BP02
Power supply DC 24V (20.4 ... 28.8V)
Current consumption max. 1.5A
Dissipation power max. 5W
Potential separation
≥ 500V AC to fieldbus
Status indicator (LEDs) like CPU 21x additionally with LEDs for the Profibus section
Adapters/interfaces like CPU 21x additionally with 9pin D-type jack (Profibus)
Profibus interface
Connector 9pin D-type jack
Network topology Linear bus, active bus termination at both ends
Medium Screened and drilled twisted pair cable. Depending on
environment screening may be omitted.
Transfer rate 9.6kBaud up to 12MBaud
Overall length 100m at 12 MBaud without repeater, up to 1000m with repeater
max. no. of stations 32 stations on every segment without repeater.
Expandable to 126 stations with repeater.
Dimensions and weight
Dimensions (WxHxD) in mm 50.8x76x80
Weight 150g
CPU 21xDPM
CPU 21xDP
