Chapter 2 Hardware description Manual VIPA CPU 21x
2-22 HB103E - Rev. 05/45
Block diagram
The following block diagram shows the basic hardware construction of the
CPU 21x modules:
Processor
System 200V
interface circuitry
System 200V
backplane bus
Memory-Card
Pulse
Clock
PU/AG
Voltage monitor
DC 24V
PW
Power
supply
RESET
RUN/STOP/MR
