Manual VIPA CPU 21x Chapter 11 Integrated OBs SFBs SFCs
HB103E - Rev. 05/45 11-43
Page frame communication - Parameterization error PAFE
The parameterization error byte PAFE is set (output or bit memory), when
the block detects a parameterization error., e.g. there is no interface or
there is an invalid parameterization of QANF/ZANF.
PAFE has the following structure:
Byte Bit 7 ... Bit 0
0 Bit 0: error
0: no error
1: error, error-No. in Bit 4 to Bit 7
Bit 1 ... Bit 3: reserved
Bit 4 ... Bit 7: error-No.
0: no error
1: wrong ORG-Format
2: area not found (DB not found)
3: area too small
4: QVZ- error
5: wrong indicator word
6: no Source-/Destinationparameters at
SEND/RECEIVE ALL
7: interface not found
8: interface not specified
9: interface overflow
A: reserved
B: invalid order-No.
C: interface of CP doesn’t quit or is negative
D: Parameter BLGR not allowed
E: reserved
F: reserved
11x 21x 31x 51x
✓ ✓ ✓
