Chapter 12 Instruction list Manual VIPA CPU 21x
Command
Operand
Parameter
Status word
Function
Length
in
BR CC1 CC0 OV OS OR STA RLO /FC
words
: Instruction depends on
: Instruction influences
12-22 HB103E - Rev. 05/45
Transfer instructions
Transfer instructions
Transfer the contents of ACCU1 into the
addressed operand. The status word is not
affected.
T
Transfer the contents of ACCU1-LL to...
IB a
0 to 127
input byte. 1/2
QB a
0 to 127
output byte. 1/2
PQB a
0 to 1023
periphery output byte. 1/2
MB a
0 to 1023
bit memory byte. 1/2
LB a
0 to 1043
local data byte. 2
DBB a
0 to 8191
data byte. 2
DIB a
0 to 8191
instance data byte. 2
g [AR1,m]
register-indirect, area-internal (AR1) 2
g [AR2,m]
register-indirect, area-internal (AR2) 2
B [AR1,m]
area-crossing (AR1) 2
B [AR2,m]
area-crossing (AR2) 2
Parameter
via parameters 2
T
Transfer the contents of ACCU1-L to ...
IW
0 to 126
input word. 1/2
QW
0 to 126
output word. 1/2
PQW
0 to 1022
periphery output word. 1/2
MW
0 to 1022
bit memory word. 1/2
LW
0 to 1042
local data word. 2
DBW
0 to 8190
data word. 2
DIW
0 to 8190
instance data word. 2
h [AR1,m]
register-indirect, area-internal (AR1) 2
h [AR2,m]
register-indirect, area-internal (AR2) 2
W [AR1,m]
area-crossing (AR1) 2
W [AR2,m]
area-crossing (AR2) 2
Parameter
via parameters 2
