VIPA CPU 21 Series User Manual

Manual VIPA CPU 21x Chapter 12 Instruction list
Command
Operand Parameter Status word Function
Length
in
BR CC1 CC0 OV OS OR STA RLO /FC
words
: Instruction depends on
: Instruction influences
HB103E - Rev. 05/45 12-23
T Transfer the contents of ACCU1 to...
ID
0 to 124
input double word. 1/2
QD
0 to 124
output double word. 1/2
PQD
0 to 1020
periphery output double word. 1/2
MD
0 to 1020
bit memory double word. 1/2
LD
0 to 1040
local data double word. 2
DBD
0 to 8188
data double word. 2
DID
0 to 8188
instance data double word. 2
i [AR1,m] register-indirect, area-internal (AR1) 2
i [AR2,m] register-indirect, area-internal (AR2) 2
D [AR1,m] area-crossing (AR1) 2
D [AR2,m] area-crossing (AR2) 2
Parameter via parameters 2
Load and transfer
instructions for
address register
Load a double word from a memory area or a
register into AR1 or AR2.
LAR1 Load the contents from...
- ACCU1. 1
AR2 address register 2. 1
DBD a
0 to 8188
data double word. 2
DID a
0 to 8188
instance data double word. 2
m 32Bit constant as pointer. 3
LD a
0 to 1040
local data double word. 2
MD a
0 to 1020
bit memory double word. 2
... into AR1.
LAR2 Load the contents from ...
- ACCU1. 1
DBD a
0 to 8188
data double word. 2
DID a
0 to 8188
instance data double word. 2
m 32Bit constant as pointer. 3
LD a
0 to 1040
local data double word. 2
MD a
0 to 1020
bit memory double word. 2
... into AR2.
TAR1 Transfer the contents from AR1 to...
- ACCU1. 1
AR2 address register 2. 1
DBD a
0 to 8188
data double word. 2
DID a
0 to 8188
instance data double word. 2
LD a
0 to 1040
local data double word. 2
MD a
0 to 1020
bit memory double word. 2
