Manual VIPA CPU 21x Chapter 12 Instruction list
Command
Operand Parameter Status word Function
Length
in
BR CC1 CC0 OV OS OR STA RLO /FC
words
: Instruction depends on
: Instruction influences
HB103E - Rev. 05/45 12-15
Load instructions
Load instructions
Loading address identifiers into ACCU1. The
contents of ACCU1 and ACCU2 are saved first.
The status word is not affected.
L Load ...
IB a
0 to 127
input byte 1/2
QB a
0 to 127
output byte 1/2
PIB a
0 to 1023
periphery input byte 2
MB a
0 to 1023
bit memory byte 1/2
LB a
0 to 1043
local data byte 2
DBB a
0 to 8191
data byte 2
DIB a
0 to 8191
instance data byte 2
... in ACCU1 2
g [AR1,m] register-indirect, area-internal (AR1) 2
g [AR2,m] register-indirect, area-internal (AR2) 2
B [AR1,m] area-crossing (AR1) 2
B [AR2,m] area-crossing (AR2) 2
Parameter via parameters 2
L Load ...
IW a
0 to 126
input word 1/2
QW a
0 to 126
output word 1/2
PIW a
0 to 1022
periphery input word
MW a
0 to 1022
bit memory word 1/2
LW a
0 to 1042
local data word 2
DBW a
0 to 8190
data word 1/2
DIW a
0 to 8190
instance data word 1/2
... in ACCU1-L
h [AR1,m] register-indirect, area-internal (AR1) 2
h [AR2,m] register-indirect, area-internal (AR2) 2
W [AR1,m] area-crossing (AR1) 2
W [AR2,m] area-crossing (AR2) 2
Parameter via parameters 2
