VIPA CPU 21 Series User Manual

Chapter 12 Instruction list Manual VIPA CPU 21x
Command
Operand Parameter Status word Function
Length
in
BR CC1 CC0 OV OS OR STA RLO /FC
words
: Instruction depends on
: Instruction influences
12-16 HB103E - Rev. 05/45
L Load ...
ID a
0 to 124
input double word. 1/2
QD a
0 to 124
output double word. 1/2
PID a
0 to 1020
periphery input double word. 2
MD a
0 to 1020
bit memory double word. 1/2
LD a
0 to 1040
local data double word. 2
DBD a
0 to 8188
data double word. 2
DID a
0 to 8188
instance data double word. 2
... in ACCU1-L.
i [AR1,m] register-indirect, area-internal (AR1) 2
i [AR2,m] register-indirect, area-internal (AR2) 2
D [AR1,m] area-crossing (AR1) 2
D [AR2,m] area-crossing (AR2) 2
Parameter via parameters 2
L Load ...
k8 8Bit constant in ACCU1-LL. 1
k16 16Bit constant in ACCU1-L. 2
k32 32Bit constant in ACCU1. 3
Parameter Load constant in ACCU1 (addressed via parameters) 2
L
2#n
Load 16Bit binary constant in ACCU1-L. 2
Load 32Bit binary constant in ACCU1. 3
L
B#8#p
Load 8Bit hexadecimal constant in ACCU1-LL. 1
W#16#p
Load 16Bit hexadecimal constant in ACCU1-L. 2
DW#16#p
Load 32Bit hexadecimal constant in ACCU1. 3
L x Load one character.
L xx Load two characters. 2
L xxx Load three characters.
L xxxx Load four characters. 3
L
D# Date
Load IEC-date (BCD-coded). 3
L
S5T#
time value
Load time constant (16Bit). 2
L
TOD#
time value
Load 32Bit time constant.
(IEC-time-of-day)
3
L
T# time
Load 16Bit time constant. 2
value Load 32Bit time constant. 3
L
C# counter
value
Load 16Bit counter constant. 2
L
P# bit
pointer
Load bit pointer. 3
L
L# Integer
Load 32Bit integer constant. 3
L Real Load real number. 3
