VIPA CPU 21 Series User Manual

Manual VIPA CPU 21x Chapter 12 Instruction list
Command
Operand Parameter Status word Function
Length
in
BR CC1 CC0 OV OS OR STA RLO /FC
words
: Instruction depends on
: Instruction influences
HB103E - Rev. 05/45 12-17
Load instructions for timer
and counter
Load a time or counter value in ACCU1, before
the recent content of ACCU1 is saved in
ACCU2.
The status word is not affected.
L T f
0 to 255
Load time value. 1/2
Timer
parameter
Load time value (addressed via parameters). 2
L C f
0 to 255
Load counter value. 1/2
Counter
parameter
Load counter value (addressed via parameters). 2
LD T f
0 to 255
Load time value BCD-coded. 1/2
Timer
parameter
Load time value BCD-coded (addressed via parameters). 2
LD C f
0 to 255
Load counter value BCD-coded. 1/2
Counter
parameter
Load counter value BCD-coded (addressed via
parameters).
2
