D-302756 35
Hex.Digit Keying
Sequence
Code
Significance
A <#>
⇒
<0> Applicable only at the beginning of a number - the dialer waits 10
seconds or waits for dial tone, whichever comes first and then dials.
D <#>
⇒
<3> Applicable only at the beginning of a number - the dialer waits 5 seconds
for dial tone and goes on hook if none is received.
E <#>
⇒
<4> Applicable only in the middle of the number - the dialer waits 5 seconds
F <#>
⇒
<5> Not applicable in phone numbers
Note: A "+" can be entered at the beginning of the line by pressing
and then .
To enter a series of digits, use the following keys:
<Numeric keypad> - to enter the number
- moves the cursor from left to right
- moves the cursor from right to left
- deletes everything after the cursor (to the right)
4.7.3.5 Configuring the Report Method (Protocol) to Monitoring Station
Continue below from the previous section or repeat steps 1 to 4 of section 4.7.3.1 before continuing with the
following instructions:
1.
or
Here you select the reporting format used by the control panel to report
events to Monitoring Stations.
2.
3.
or
Select between "SIA", "4/2 1900/1400", "4/2 1800/2300",
"Scancom", "SIA text" and "contact ID".
4.
5.
Here you select the pulse rate at which data will be sent to Monitoring
Stations if any one of the 4/2 formats has been selected in PSTN Report
Format.
6.
7.
or
Select between "10 pps", "20 pps", "33 pps" and "40 pps".
8.
You can now press the button to take you to the "
PSTN RPRT
RETRY
" menu, or press the button to take you to "
<OK> TO
EXIT
".
4.7.3.6 Configuring the Number of Retry Attempts
Continue below from the previous section or repeat steps 1 to 4 of section 4.7.3.1 before continuing with the
following instructions:
1.
or
REPORT EVENTS
4/2 PULSE RATE
4/2 PULSE RATE
PSTN RPRT FORMAT
REPORT EVENTS
20 pps
SIA
PSTN RPRT FORMAT
