Wacker Neuson RD40 User Manual

Maintenance
Water sprinkling
158
BA RD40_RD45 en 00
1
1
3 2 4
6 5
Switch off diesel engine and remove ignition key.
Unscrew the filter head [1] from the water tank and remove it together
with the pressure spring [2] (be careful with the sealing rings [3] on
the filter head).
Pull the filter insert [4] from the water tank.
Clean filter insert and compression spring.
Empty the water tank when the filter has been removed.
Place the filter insert [4] into the water tank.
Screw the filter head [1] with the seal rings [3] together with the
pressure spring [2] into the water tank.
Use the wrench [5] to screw the filter head out and in. The
wrench [6] is included in the on-board tool as an option.
The filter insert must be replaced by a new one when it is
defective, worn out or cannot be cleaned.
For ordering, please contact the customer service.
4.08.05 Emptying and cleaning the water sprinkling system
3
1
2
