Auxiliary equipment
HAMM line spreader
BA RD40_RD45 en 00
221
Mounting chip spreader
Lift the chip spreader on to the suspension eyelets [1]
Put the grit spreader on the holder at the machine frame and align it.
Connect 2 x lower links [2] with socket pins and secure them with split
pins.
Connect the upper connecting rod [3] with cotter pins and secure with
split-pins.
Connect the hydraulic connectors [4].
Connect the lighting connector [5].
Removing the chip spreader
Empty the storage container.
Disconnect the lighting [5] and hydraulic connectors [4].
Close the hydraulic hoses [4].
Attach the chip spreader to the suspension eyelets [1].
Remove the securing elements and split-pins.
Remove the socket pins from upper link [3] and lower links [2].
Lift the chip spreader on the suspension eyes [1] off the machine
frame.
Park the chip spreader safely and secure against tipping.
6.07.03 Operation
WARNING
Exposed, rotating parts!
Risk of being trapped, pulled in, and injured by rotating chip spreader
parts.
■
Do not perform any testing, adjusting or maintenance work unless
the diesel engine has been switched off.
■
Do not reach with your hands into the chip spreader unless after
every part has come to a standstill.
■
Do not lay down any object or tool in the chip spreader.
■
Keep a safety distance when making a visual inspection while the
diesel engine is running.
NOTICE
Heavy weight, High line load!
Cracks and displacements of the asphalt caused by a high line load
imposed by the drum.
■
Do not drive over hot asphalt with a full storage container for the
chip spreader.
