Tables
Technical data
BA RD40_RD45 en 00
179
5.01.05 RD45-140o
Designation Value Unit
Dimensions and weights
Unladen weight without ROPS roll-over bar 4215 kg
Operating weight with ROPS roll-over bar 4535 kg
Front/rear axle load 2250/2280 kg
Working width/max. working width 1380/1430 mm
Inside/outside turning radius 2650/4030 mm
Diesel engine
Manufacturer Kubota
Type V2403-CR
Number of cylinders 4
Power (ISO 14396)/rated speed 37.4/2700 kW/rpm
Exhaust emissions category EU/USA V/Tier 4
Carbon dioxide emissions (CO
2
)
(1)
834.6 g/kWh
Travel drive
Working gear speed 0–11.0/(0–6.8) km/h/(mph)
Gradeability with/without dynamic compaction system 30/40 %
Max. permitted longitudinal incline 20 °
Max. permitted transverse incline 20 °
Vibration
Vibration front
Stage 1: Frequency/speed 60/3600 Hz/rpm
Stage 1: Max. amplitude 0.51 mm
Stage 2: Frequency/speed 51/3060 Hz/rpm
Stage 2: Max. amplitude 0.31 mm
Oscillation
Oscillation rear
Stage 1: Frequency/speed 39/2340 Hz/rpm
Stage 1: Tangential amplitude 1.37 mm
Stage 2: Frequency/speed 30/1800 Hz/rpm
Stage 2: Tangential amplitude 1.37 mm
Steering
Steering lock to both sides 33 °
Pendulum compensation upwards and downwards 8 °
Track offset
Track offset to the right 50 mm
Filling capacities
Fuel 73.00 l
Engine oil (for oil change) 9.50 l
