Operation
Adjusting the driver's seat
BA RD40_RD45 en 00
67
3.05 Adjusting the driver's seat
WARNING
Uncontrolled motion!
Injuries due to uncontrolled movements when changing the driver's
seat position when driving.
■
Only drive with latched operator’s seat.
■
Do not adjust the driver's seat during travel.
■
Free access to bodywork and engine parts.
The seat is adjusted to suit the size of the driver's body with the various
setting options.
Set driver's weight
There is damping built into the driver's seat that compensates for shock-
like machine movements. For this damping to function optimally, the seat
must be adjust to the weight of the driver.
The driver's weight can be adjusted in 9 steps between 50 kg and 130 kg.
The handle for setting the weight must only be pushed
downwards from above.
Push the handle [1] down hard towards the end stop.
a
The weight setting is adjusted upwards to its 50 kg home position.
Push the handle [1] downwards and set the driver's weight.
Adjusting the inclination of the backrest
Open detent: Turn the handwheel [2] 30° clockwise and hold.
Adjust the backrest steplessly forwards or backwards.
Release the handwheel [2].
a
Detent closes automatically and the inclination of the backrest is
adjusted.
