Wacker Neuson RD40 - Dimension Sheet; RD40-130, RD40-130 O; RD40-130 C

Tables
Dimension sheet
BA RD40_RD45 en 00
183
5.02 Dimension sheet
5.02.01 RD40-130, RD40-130o
Bildnummer
1820
(71.7")
305
(12.0")
63
(2.5")
63
(2.5")
2590
(102.0")
720
(28.4")
2800
(110.0")
1950
(76.8")
1300
(51.2")
17
(0.7")
1426
(56.1")
1426
(56.1")
1300
(51.2")
3043
(119.8")
2896
(114.0")
Ø 900
(35.4")
17
(0.7")
Ø 900
(35.4")
5.02.02 RD40-130c
Bildnummer
1820
(71.7")
305
(12.0")
126
(5.0")
12
(0.5")
25
(1.0")
25
(1.0")
12
(0.5")
275
(10.8")
275
(10.8")
63
(2.5")
63
(2.5")
2590
(102.0")
720
(28.4")
2800
(110.0")
1950
(76.8")
1300
(51.2")
17
(0.7")
1426
(56.1")
1276
(50.2")
3043
(119.8")
2896
(114.0")
Ø 900
(35.4")
Ø 810
(31.9")
