Operation
Driving with water sprinkling system
BA RD40_RD45 en 00
93
3.17 Driving with water sprinkling system
After each engine start water sprinkling system is deactivated.
The water sprinkling system wets the drums/tyres and the edge pressure
and cutting device with water. The wetting prevents that bitumen sticks on
roller drums/tyres when laying blacktops. This is the way to make a neat
and even covering.
An electric water pump supplies the water sprinkling system with water.
The built-in automatic sprinkling unit adjusts the water consumption to
match the conditions of use optimally. A multilevel automatic interval
system determines the minimum use of water for optimum moisturing,
using a combination of spray quantity and pump pause time. The water
pump can also be switched manually to continuous operation at any time.
The sprinkling control is switched off at a road speed of less
than 0.5 km/h (0.3 mph).
Continuous operation is still possible in this case.
Sprinkling the roller drum/tyres
Requirement: Diesel engine is running, water sprinkling system is
activated.
When the driving speed exceeds 0.5 km/h (0.3 mph) the sprinkling is
switched on.
When the machine is at a standstill, the sprinkling is switched off.
Setting the sprinkler to on or off
Activating water sprinkling system
Requirement: Electrical system ON
Press switch [1].
a
The luminous spots [3] show the current sprinkling stage.
a
Pilot LED [2] is on when the sprinkler has been switched on via the
automatic interval control.
Deactivating water sprinkling system
Press switch [1] again.
a
Water sprinkling system is deactivated.
