Tables
Fuses
186
BA RD40_RD45 en 00
5.03.02 Steering column
[3] Central electrical system/option 1
Component Fuse assignment Fuse
F1 All-wheel lock 5 A
F2 Seat belt 1 A
F3 Drum lighting 10 A
F4 Left driving light 10 A
F5 Right driving light 10 A
F6 Reversing lights 15 A
F7 Working spotlights 15 A
F8 Reserve 1 5 A
F9 KAG control unit 5 A
F10 Water sprinkling foot pedal 15 A
F11 Additive sprinkling foot pedal, seat heating, HCMCL 15 A
F12 Reserve 2 10 A
F13 Socket 15 A
F14 Signal horn 15 A
F15 Additive sprinkling pump 15 A
F16 Water sprinkling pump 15 A
F17 Rotating beacon 15 A
F28 Vibration relay switching 10 A
F35 Dashboard (terminal 30) 20 A
F36 Dashboard (terminal 15) 25 A
FT Plug-in socket for fuse test
You can use the fusible test receptacle to check a fuse.
The green light-emitted diode (LED) lights up when the fuse is functional.
5.03.03 Electrical box
[4] Central electrical system/option 2
Component Fuse assignment Fuse
F20 Diesel engine control unit 25 A
F21 Fuel pump 5 A
F22 Sensors at the diesel engine 5 A
F23 Sensors on the machine 5 A
F24 Cab actuation option (terminal 15) 5 A
F25 Ignition on 5 A
F26 Interface XT1 (terminal 30) 5 A
F27 Cab option (terminal 30) 10 A
You can use the fusible test receptacle to check a fuse.
The green light-emitted diode (LED) lights up when the fuse is functional.
