Wacker Neuson RD40

Operation
Opening and closing the engine hood
72
BA RD40_RD45 en 00
3.08 Opening and closing the engine hood
1
3
22
Opening the engine hood
Use the ignition key in the lock on the handle [2] to unlock the engine
hood [1].
Press the push-button on the handle [2].
Raise the engine hood [1].
a
The engine hood is open.
a
The engine hood is held in place by pneumatic springs [3].
Closing the engine hood
Lower the engine hood [1] and push it into the lock.
Use the ignition key in the lock on the handle [2] to lock the engine
hood [1].
a
The engine hood is closed.
The engine hood must be locked while the machine is
operating.
