WAGNER VU 1 - Page 51

51
VERSION 03/2020 ORDER NUMBER DOC2330732
VU 1/VU 2/VU 3
Procedure:
1. Using an Allen wrench, open bolts (1) by one revolution.
2. Next, tighten the drive belt to the extent that it can still be deected by hand with
little eort.
3. Tighten/loosen the drive belt in stages with half turns of tensioning bolt (2), until a
slight deection is perceptible.
4. Tighten tensioning bolt (2) by a further quarter turn.
The drive belt should no longer be deected. If it is, then tighten tensioning bolt (2)
by a further quarter turn.
5. Retighten bolts (1).
6. Reattach the front cover on the reciprocator.
