5-60 Maintenance Procedures
3. Using the combined 2.5-mm Allen wrench and cone extraction tool,
remove the 3 probe end cover retaining screws.
4. Remove the end cover and gasket from the probe assembly.
5. Unscrew and remove the nebulizer adjuster knob.
End cover retaining screws
End cover
Nebulizer adjuster knob
Gasket
