General Information 40075165 Markoprint integra PP108
Page 9 of 104 GB
Explanation of Technical Terms
Technical Term
Explanation
Conveyor
The conveyor transports the products, which should be
printed and pass them by the print head
DPI
Dots Per Inch
1 Inch = 25,4mm
Encoder
See shaft encoder
LED
Light emitting diode
Nozzle plate
On the nozzle plate are 500 nozzles arranged, which
ejected the ink.
Print direction
Direction of movement of the product on the conveyor belt
viewed from the control system in the print direction
Print intensity
Contrast of the print image. If necessary this parameter
must be changed to optimize the print image. A higher
intensity gives greater blackening and longer ink drying time
Print speed
Print speed = Speed of the conveyor. The speed of the
conveyor must be keep constant
Print start delay
Offset print, i.e. by how much is printing delayed in
millimeters after the product is detected by the light barrier.
Print width
The number of pixel can be increased or decreased using
this parameter. The print image becomes narrower or
wider.
Product sensor
A sensor for the detection of the product. Mostly used are
optical sensors (photo sensor, light barrier, reflex sensor)
Sensor
See Product-sensor
Shaft encoder
A shaft encoder is used for the automatic detection of the
conveyor speed and defines the print speed
Seiko
Manufacturer of the print head module
